Article number: 3BSE093005R1

Type: Ground Fault Detection Module

Number of channels: 1

Signal specification: 0…1 Mohm

HART: N/A

SOE: N/A

Redundancy: No

Hot swap: Yes

High integrity: No

Intrinsic safety: No

Mechanics: Select I/O

Supported field devices: -

Isolation: Galvanic isolation to system. Routine tested at factory with 3060 VDC.

Field power: -

Accuracy: ±15 %

Diagnostics: Internal hardware supervision, Communication supervision, Internal power supervision

Calibration: Factory calibration

Power dissipation: 0.4 W

Installation in Hazardous Area/Locations: Yes/Yes (on IPA)

IS barrier: No

Field Input Robustness: ±35 V between all terminals

Input voltage range: 19.2...30 V

Temperature, Operating: -40 °C (-40 °F) to +70 °C (158 °F)

Temperature, Storage: -40 °C (-40 °F) to +85 °C (185 °F)

Pollution degree: Pollution Degree 2 acc. to IEC 60664-1

Relative humidity: 5 to 95 %, non-condensation

Altitude: -1000 to 5000 m (restrictions apply)

Mechanical operating conditions: IEC 61131-2

EMC: IEC/EN 61000-6-4, IEC/EN 61000-6-2

Overvoltage categories: Category II acc. to IEC 60664-1

Protection class: IP20 acc. to IEC 60529

CE-marking: Yes

UKCA: Yes

Electrical Safety: IEC/EN 61010-1, UL 61010-1, CSA-C22.2 No. 61010-1-12, IEC/EN 61010-2-201, UL 61010-2-201, CSA C22.2 No. 61010-2-201

Marine certification: N/A

Corrosive atmosphere: G3

RoHS compliance: EU RoHS, UAE RoHS, CN RoHS

WEEE compliance: EU

ATEX: II 3G Ex ec IIC T4 Gc, II 3G Ex ic ec IIC T4 Gc

IECEx: Available on IPA: II 3G Ex ec IIC T4 Gc, II 3G Ex ic ec IIC T4 Gc

US/CAN: Available on IPA: cULus CL I, ZN 2, AEx ec IIC T4 Gc, Ex ec IIC T4 Gc X CL I, DIV 2, Groups A-D T4

CCC: No

Width: 77.9 mm

Depth: 108 mm

Height: 9.8 mm

Weight (including base): 76 g
