IC697MDL340 GE Fanuc Series 90-70 Discrete Output Module
Manufacturer:
GE
Product No.:
IC697MDL340
Condition:
In Stock
Product Type:
Discrete Output Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specification:
- Rated Voltage: 120 volts AC
- Outputs per Module: 16 (organized into four groups of four outputs each)
-
Isolation:
- 1500 volts (any output to backplane)
- 500 volts (between groups)
- Output Voltage Range: 85 to 132 volts, 47 to 63 Hz
-
Output Current:
- 2 amps maximum per point
- 4 amps maximum per group
-
Output Characteristics:
- Inrush Current: 20 amps maximum for one cycle (20 ms)
- Output Voltage Drop: 3 volts maximum
- Response Time–On: 1 ms maximum
- Response Time–Off: 1/2 cycle
- Output Leakage: 1.5 mA maximum
- Current Required from 5V Bus: 0.25 amp
- VME System Compliance: Designed to support VME standard C.1
- Dimensions: 1.5" x 11.5" x 9.0" (3.8 cm x 29.2 cm x 22.9 cm)
- Weight: 1 lbs 1.0 oz (0.5 kg)
