Honeywell CC-TUIO41 Universal Input Output IOTA Redundant

In stock
Manufacturer:
Honeywell
Product No.:
CC-TUIO41
Condition:
In Stock
Product Type:
UIO-2 IOTA Redundant
Product Origin:
USA
Weight:
670g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Honeywell CC-TUIO41 Universal Input Output IOTA Redundant

Description

The Honeywell CC-TUIO41 is a Universal Input/Output (I/O) Termination Assembly (IOTA) module designed for industrial automation applications. It is particularly suited for use in sectors such as power generation, oil and gas, chemical processing, mining, and pharmaceutical manufacturing. This module supports both analog and digital signals, making it a versatile component for various input and output configurations.

Features

  • Redundancy: Ensures high reliability and system uptime through redundant configurations.
  • Versatile Input/Output: Supports a combination of analog, digital, and pulse inputs/outputs.
  • Wide Input Voltage Range: Handles input voltages from -10 to +110 VDC.
  • Current Handling: Manages input currents from 0 to 22 mA and output currents up to 20 mA.
  • Environmental Robustness: Operates in extreme temperatures ranging from -40 to +85°C, with high resistance to shock and vibration.
  • Ingress Protection: Rated IP67, ensuring protection against dust and water ingress.

Specifications

  • Number of Channels: 2 universal I/O channels.
  • Input Voltage Range: -10 to +110 VDC.
  • Input Current Range: 0 to 22 mA.
  • Output Voltage Range: 0 to 10 VDC.
  • Output Current Range: 0 to 20 mA.
  • Operating Temperature Range: -40 to +85°C.
  • Storage Temperature Range: -40 to +85°C.
  • Vibration: 5 to 500 Hz, 0.025 in. (0.64 mm) peak-to-peak.
  • Shock: 25 g, 11 ms, half-sine.
  • Humidity: 5 to 95% non-condensing.
  • Dimensions: Approximately 8.5 x 5.5 x 2.5 inches.
  • Weight: 1 pounds (0.5 kg).

Removal of a UIO-2 and LLAI Modules

  1. On the IOTA, set the applicable switch (POWER 1 or POWER 2) to OFF. Ensure the Power LED (green) turns off.
  2. Completely loosen the two locking screws.
  3. Remove the module from the IOTA.

Installation of a UIO-2 and LLAI Modules

  1. On the IOTA, make sure that the applicable switch (POWER 1 or POWER 2) is set to OFF.
  2. Hold the module in the correct position on the IOTA and carefully push it down on the corresponding connectors.
  3. Tighten the two locking screws to 1.3 Nm or 12 in. lbs.
  4. On the IOTA, set the applicable switch (POWER 1 or POWER 2) to ON. Ensure the Power LED (green) turns on.
