DI885 Digital Input Module
The DI885 Digital Input Module has 8 channels for 48 volt d.c. digital inputs with or without open-circuit monitoring (wire break supervision), or 24 volt d.c. electronic inputs without open-circuit monitoring; and sequence of events (SOE) handling capabilities. The sequence of events timestamp has a resolution of 1 ms for each input channel. The inputs are arranged in one group of 8 channels. Each input channel provides current limiting, EMC protection, input state LED indicator, and optical isolation from the ModuleBus. The DI885 also has the capability to monitor an internal or external sensor power supply (60 V d.c. max.).
DI885 Digital Input Module Features
- Channels: 8 channels for 24/48 V d.c. inputs with current sinking.
- Indicators: Input status indicators.
- Sequence of Events (SOE): Yes, with 1 ms resolution.
- Sensor Power Supply: External 24 or 48 V d.c. sensor power supply; Internal 48 V d.c. sensor power supply.
- Protection: Short circuit protection to ground and 48 Volt.
- Supervision: Channel supervision; Sensor power supply supervision.
- Filter: Shutter filter.
Technical Data
| Feature | Specification |
|---|---|
| Number of channels | 8, current sinking |
| Power supply | |
| Nominal voltage | 24 V d.c. |
| Operating voltage range | 19.2 to 30 V d.c. |
| Process power supply (UP) | |
| Nominal voltage with internal supply | 48 V d.c.+/- 10% |
| Voltage range with external supply | 18 V d.c. - 60 V d.c. |
| Input signal (48 V contact supervised) | |
| "1" | >30 V d.c....2 mA...8 V d.c. (0.5 mA) |
| Open circuit | 30 V d.c....2 mA...-30 V d.c. (-2.2 mA) |
| Input signal (24 V electronic not supervised) | |
| "1" | >8 V d.c....0.5 mA...-30 V d.c. (-2.2 mA) |
| Input impedance | 15 kΩ |
| Maximum field cable length | 600 meters, (656 yd.) |
| Bounce filter times (digital, selectable) | 0 to 255 ms |
| Event recording resolution | 1 ms |
| Event recording accuracy | -0.5 ms to +1.3 ms |
| Shutter filter | |
| Shutter period | 0... 255 s |
| Shutter trigger | 0.. 255 changes |
| Recovery time | 0... 65535 s |
| Process voltage supervision per device | Yes |
| Current consumption | |
| 5 V (Modulebus) | 160 mA |
| 24 V (Modulebus) | 91 mA |
| 24 V (process power supply, UPx) | 91 mA |
| 48 V (process power supply, UPx) | 22 mA |
| Power dissipation | 3 W |
| Isolation | Yes, opto |
| Module termination units | TU810, TU812, TU814, TU818, TU830, or TU833 |
| MTU keying code | BF |
| Rated insulation voltage | 50 V |
| Dielectric test voltage | 500 V a.c. |
Dimensions
| Feature | Specification |
|---|---|
| Product Net Depth / Length | 102 mm |
| Product Net Height | 119 mm |
| Product Net Width | 45 mm |
| Product Net Weight | 0.3 kg |
