CI857 - General Info

Article Number: 3BSE018144R1
Communication Protocol: ABB's INSUM
Master or Slave: Master
Transmission Speed: 10 Mbit/s
Line Redundancy: No
Module Redundancy: No
Hot Swap: Yes
Used Together with HI Controller: Yes

Detailed Data

Max Units on CEX Bus: 6
Connector: RJ-45 female (8-pin)
24 V Consumption Typ.: Typ 150 mA

Environment and Certification

Temperature, Operating: +5 to +55 °C (+41 to +131 °F)
Temperature, Storage: -40 to +70 °C (-40 to +158 °F)
Corrosion Protection: G3 compliant to ISA 71.04
Protection Class: IP20 according to EN60529, IEC 529
CE-Marking: Yes
RoHS Compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions

Width: 59 mm (2.3 in.)
Height: 185 mm (7.3 in.)
Depth: 127.5 mm (5.0 in.)
Weight (Including Base): 700 g (1.5 lbs)
