Analog Input Module ABB AIS830 2PAA123605R1
Analog Input Module ABB AIS830 2PAA123605R1
ABB

Analog Input Module ABB AIS830 2PAA123605R1

In stock
Manufacturer:
ABB
Product No.:
AIS830
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
CH
Weight:
52g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

AIS830 Analog Input Module

General Information

  • Article Number: 2PAA123605R1
  • Type: Analog Input Module
  • Channels: 1
  • Signal Types: RTD/TC/mV
  • Redundancy: No
  • Hot Swap: Yes
  • High Integrity: No
  • Intrinsic Safety: No
  • Mechanics: Select I/O

Specifications

  • Supported Field Devices:
    • 2-wire, 3-wire
  • Supported RTD Inputs:
    • Pt100, Pt200, Pt500, Pt1000, Ni100, Ni120, Ni200, Ni500, Ni1000, Ni1200, Cu10, R (0 to 4000 Ω)
  • Supported TC Inputs:
    • B, C, D, E, J, K, L, N, R, S, T, U and -30 mV to +75 mV
  • Isolation: Galvanic isolation to system and between each channel (including field power)
  • Factory Testing: 3060 VDC
  • Field Power: Current limited
  • Accuracy: 0.1%
  • Resolution: 16-bit D/A converter
  • Diagnostics:
    • Loop supervision (short circuit, open circuit)
    • Communication supervision
    • Internal power supervision
  • Calibration: Factory calibration
  • Power Dissipation: 0.4 W

Environment and Installation

  • Hazardous Area Installation: Yes (Pending certification)
  • IS Barrier: No
  • Field Input Robustness: ±35 V between all terminals
  • Operating Temperature: -40 °C to +70 °C (-40 °F to 158 °F)
  • Storage Temperature: -40 °C to +85 °C (-40 °F to 185 °F)
  • Pollution Degree: 2 (IEC 60664-1)
  • Relative Humidity: 5% to 95% (non-condensing)
  • Altitude: -1000 m to 5000 m (restrictions apply)
  • Mechanical Conditions: IEC 61131-2
  • EMC Standards: IEC/EN 61000-6-4, IEC/EN 61000-6-2
  • Overvoltage Categories: Category II (IEC 60664-1)
  • Protection Class: IP20 (IEC 60529)
  • Certifications: CE, UKCA

Compliance

  • Electrical Safety Standards:
    • IEC/EN 61010-1, UL 61010-1, CSA-C22.2 No. 61010-1-12
    • IEC/EN 61010-2-201, UL 61010-2-201, CSA C22.2 No. 61010-2-201
  • RoHS Compliance: EU, UAE, CN
  • WEEE Compliance: EU

Hazardous Area Ratings

  • ATEX Certification:
    • II 3G Ex ec IIC T4 Gc
    • II 3G Ex ic ec IIC T4 Gc
  • IECEx Certification:
    • II 3G Ex ec IIC T4 Gc
    • II 3G Ex ic ec IIC T4 Gc
  • Hazardous Location US/CAN: Pending
  • Hazardous Area CCC: No

Dimensions and Weight

  • Width: 77.9 mm
  • Depth: 105 mm
  • Height: 9.8 mm
  • Weight (including base): 52 g
