General Info

• General Info

  • Article Number: 3BSE018106R1
  • Communication Protocol: ABB's MasterBus 300
  • Master or Slave: Master
  • Transmission Speed: 10 Mbit/s, 200 Datasets/s
  • Line Redundancy: Yes
  • Module Redundancy: No
  • Hot Swap: Yes
  • Used Together with HI Controller: Yes

  Key Benefit: The CI855 interface allows for peer-to-peer communication between new plant sections using System 800xA with the AC 800M controller and existing sections with MB 300-based controllers such as Advant Controller 410, Advant Controller 450, and MasterPiece 200/1.

Detailed Data

• Max Units on CEX Bus: 12
• Connector: RJ-45 female (8-pin)
• 24 V Consumption (Typical): 150 mA

Environment and Certification

• Temperature, Operating: +5 to +55 °C (+41 to +131 °F)
• Temperature, Storage: -40 to +70 °C (-40 to +158 °F)
• Corrosion Protection: G3 compliant to ISA 71.04
• Protection Class: IP20 according to EN60529, IEC 529
• CE-Marking: Yes
• Marine Certificates: BV, DNV-GL, LR
• RoHS Compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
• WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions

• Width: 59 mm (2.3 in.)
• Height: 185 mm (7.3 in.)
• Depth: 127.5 mm (5.0 in.)
• Weight (including base): 700 g (1.5 lbs)
