AIS880 Analog Input Module

General Information

• Article Number: 3BSE074053R1
• Type: Analog Input Module - SIL3
• Number of Channels: 1
• Signal Specification: 4...20 mA
• HART: Yes
• Detailed HART Information: HART v7, HART pass-through, and HART variables to the application
• SOE: N/A
• Redundancy: Yes
• Hot Swap: Yes
• High Integrity: Yes
• Intrinsic Safety: No
• Mechanics: Select I/O

Detailed Data

• Supported Field Devices: 2-wire and 4-wire devices (external power required for 4-wire devices)
• Isolation: Galvanic isolation to system and between each channel (including field power)
• Factory Testing: 3060 VDC
• Field Power: Current limited to 30 mA
• Accuracy: 0.1%
• Resolution: 16-bit A/D converter
• Diagnostics:
  • Loop supervision (open circuit, short circuit)
  • Device malfunction low, under range, over range, and device malfunction high
  • Internal hardware supervision
  • Communication supervision
  • Internal power supervision
• Calibration: Factory calibration
• Power Dissipation: 0.62 W at 20 mA

Environment and Certification

• Temperature, Operating: -40 °C (-40 °F) to +70 °C (158 °F)
• Temperature, Storage: -40 °C (-40 °F) to +85 °C (185 °F)
• Pollution Degree: Pollution Degree 2 acc. to IEC 60664-1
• Relative Humidity: 5% to 95%, non-condensing
• Altitude: -1000 to 5000 m (restrictions apply)
• Mechanical Operating Conditions: IEC 61131-2
• EMC: IEC/EN 61000-6-4, IEC/EN 61000-6-2
• Overvoltage Categories: Category II acc. to IEC 60664-1
• Protection Class: IP20 acc. to IEC 60529
• CE-Marking: Yes
• UKCA: Yes

Electrical Safety

• Standards:
  • IEC/EN 61010-1, UL 61010-1, CSA-C22.2 No. 61010-1-12
  • IEC/EN 61010-2-201, UL 61010-2-201, CSA C22.2 No. 61010-2-201

Marine Certification

• Certification: DNV, ABS

Hazardous Area Ratings

• ATEX:
  • II 3G Ex nA IIC T4 Gc
  • II 3G Ex ec IIC T4 Gc
  • II 3G Ex ic nA IIC T4 Gc
  • II 3G Ex ic ec IIC T4 Gc
• IECEx:
  • II 3G Ex nA IIC T4 Gc
  • II 3G Ex ec IIC T4 Gc
  • II 3G Ex ic nA IIC T4 Gc
  • II 3G Ex ic ec IIC T4 Gc
• Hazardous Location US/CAN: cULus
• CL I, ZN 2, AEx ec IIC T4 Gc, Ex ec IIC T4 Gc X
• CL I, ZN 2, AEx nA IIC T4 Gc, Ex nA IIC T4 Gc X
• Non-incendive use for CL I, DIV 2, Groups A-D T4

Functional Safety

• Standards:
  • IEC 61508 Ed. 2, SIL 1-3
  • IEC 61511-1
  • IEC 62061
  • IEC 61131-2, IEC 61131-6
  • IEC 60204-1
  • NFPA 72, NFPA 79, NFPA 85, NFPA 86
  • EN ISO 14118
  • EN 50156-1
  • EN 298
  • EN 54-2, EN 54-2 A1
  • EN ISO 13850

Dimensions and Weight

• Width: 77.9 mm
• Depth: 105 mm
• Height: 9.8 mm
• Weight (including base): 73 g
