🔧 Features

• Connection Methods:
  • Supports both star and chain type connections.
  • Can be configured for up to two stages of connection.
• Extended Transmission Distance:
  • Maximum transmission distance of 5 km for standard configurations (two stages).
  • In Vnet/IP systems (R1.03 or later), the total distance can extend up to 10 km.
• Current Efficiency:
  • Low current consumption of 0.5 A, ensuring energy efficiency.
• Compact Design:
  • Lightweight at approximately 0.3 kg, facilitating easy installation in various environments.
• Dimensions:
  • Measures 142.5 x 32.8 x 32.8 mm, suitable for compact spaces.

📊 Technical Specifications

• Functionality:
  • ESB Bus optical transport for industrial communication.
• Connection Type:
  • Star and chain type connection compatibility.
• Number of Stages:
  • Maximum of two connecting stages.
• Maximum Transmission Distance:
  • 5 km (standard).
  • 10 km (for Vnet/IP systems with R1.03 or later).
• Current Consumption:
  • 0.5 A.
• Weight:
  • Approximately 0.3 kg.
• Dimensions:
  • 142.5 mm (L) x 32.8 mm (W) x 32.8 mm (H).
