Description

The AAV141-S50 Current/Voltage Input Modules is designed for accepting standardized signals from 2-wire or 4-wire transmitters, offering 16 non-isolated input channels. These modules support dual-redundant configurations for enhanced reliability and are suitable for a range of industrial applications requiring precise data acquisition.

Features

• Number of Input Channels:

  • AAV141: 16, non-isolated (differential input)



• Input Signal Options:

  • 1 to 5 V DC (allowable common mode voltage ± 1 V or less)

• Allowable Input Current/Voltage: ±7.5 V



• Withstanding Voltage: Not specified for non-isolated modules

• Input Resistance:

  • Power ON: 1 MΩ or larger
  • Power OFF: 340 kΩ or larger

• Accuracy: ±4 mV

• Data Update Period: 10 ms

• Step Response Time: 100 ms

• Temperature Drift:±4 mV/10 °C



• Maximum Current Consumption: 350 mA (5 V DC)

• External Connection: Pressure clamp terminal, KS cable, MIL connector cable

Specifications

• Model: AAV141-S50 Analog Input Module (1 to 5 V, 16-channel, Non-Isolated)

• Suffix Codes:

  • -S: Standard type
  •   -5: With no explosion protection
  •   -E: With explosion protection
  •     -0: Basic type
  •     -3: With ISA Standard G3 option and temperature (-20 to 70 °C) option

• Option Codes:

  • /K4A00: With KS Cable Interface Adapter [Model: ATK4A-00]
  • /A4S00: With Pressure Clamp Terminal Block for Analog [Model: ATA4S-00]
  • /A4S10: With Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4S-10]
  • /A4D00: With Dual Pressure Clamp Terminal Block for Analog [Model: ATA4D-00]
  • /A4D10: With Dual Pressure Clamp Terminal Block for Analog (surge absorber) [Model: ATA4D-10]
  • /CCC01: With Connector Cover for MIL Cable [Model: ACCC01]

Weight and Dimensions

• Weight: 0.2 kg
• Dimensions: 130 mm x 107.5 mm x 32.8 mm
