X20SM1436 B&R X20-SM1436 Motor module
Manufacturer:
B&R
Product No.:
X20SM1436
Condition:
In Stock
Product Type:
Motor module
Product Origin:
USA
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Short Description
- I/O module: 1 full bridge for controlling stepper motors
Power Consumption
| Bus | 0.01 W |
| Internal I/O | - |
| External I/O (24 VDC) | 2.2 W |
| External I/O (48 VDC) | 3 W |
Input Current Limiting
- Max. 10 A
Motor Bridge - Power Unit
| Quantity | 1 |
| Type | 2-phase bipolar stepper motor (full bridge) |
| Nominal Voltage | 24 to 48 VDC ±25% |
| Nominal Current | 2.5 A |
| Maximum Current | 3.5 A for 1 s |
| DC Bus Capacitance | 100 µF |
| Step Resolution | Max. 256 microsteps per step |
| Module Power Supply | External |
| Fuse | Required line fuse: Max. 10 A, slow-blow |
| Output Protection | Reverse polarity protection on supply voltage |
Digital Inputs
| Quantity | 4 |
| Nominal Voltage | 24 VDC |
| Input Circuit | Sink |
| Input Filter | Hardware: < 5 µs |
| Software | - |
| Connection Type | 1-wire connections |
| Input Resistance | Typ. 10 kΩ |
| Additional Functions | 1x ABR incremental encoder, open-circuit detection |
| Switching Threshold | Low: < 5 VDC High: > 10 VDC |
ABR Incremental Encoder
| Quantity | 1 |
| Encoder Inputs | 24 V, asymmetrical |
| Counter Size | 16-bit |
| Input Frequency | Max. 50 kHz |
| Evaluation | 4x |
Ambient Conditions
| Temperature | Operation: Horizontal mounting orientation: -25 to 50°C Vertical mounting orientation: -25 to 50°C Derating: See section "Derating". Storage: -25 to 70°C Transport: -25 to 70°C |
| Relative Humidity | Operation: 5 to 95%, non-condensing Storage: 5 to 95%, non-condensing Transport: 5 to 95%, non-condensing |
