Overview:

• Manufacturer: General Electric (GE)
• Model: UR-6AV
• Product Name: Digital I/O Module

Key Features of the UR-6AV Module:

• Provides 2 Form-A type digital outputs and 2 Form-C type digital outputs
• Form-A outputs have a single normally open contact, while Form-C outputs have normally open, normally closed, and common contacts
• All output contacts are isolated from signal ground
• Provides 8 digital inputs
• Supports voltage and optional current monitoring capabilities
• Utilizes FlexLogic programmable logic for flexible system configuration
• Fast activation speed, with Form-A outputs less than 4 ms

Differences from Other Modules:

• The UR-6AV module is unique in its combination of Form-A and Form-C output types.
• Other modules may only provide Form-A or Form-C outputs, or a different number of outputs.
• The UR-6AV does not have a mechanical latching configuration but can help eliminate the need for latching relays.
• The 6V model offers more output and input options but does not include the Form-A and Form-C combination.
