Honeywell MC-TPIX12: High-Speed Pulse Input Module for Precision Monitoring

Ultra-Fast Pulse Counting for Critical Applications

• 8-channel pulse counter with 10kHz max frequency
• High-sensitivity 0.5V detection for weak signals
• Rugged design withstands 20g shock and 2g vibration
• 12Mbps data rate for real-time processing

Technical Specifications

• Brand/Model: Honeywell MC-TPIX12 (51304084-175)
• Input Type: 0-30VDC pulse signals
• Resolution: 32-bit counter per channel
• Min Pulse Width: 10μs
• Temp Range: -25°C to 65°C operation
• Isolation: 500V channel-to-channel
• Power Supply: 24VDC ±10%
• Dimensions: 30.8 x 12.1 x 7.2 cm

Installation & Compatibility

• Tool-less DIN rail mounting
• Compatible with Honeywell TDC/TPS systems
• Hot-swappable design for maintenance

Professional FAQ

• Q: What types of sensors are supported?
  A: Compatible with proximity switches, encoders, and pulse generators
• Q: Can it measure pulse duration?
  A: Yes - measures width from 10μs to 100ms
• Q: Is filtering available for noisy signals?
  A: Yes - configurable digital filtering
• Q: What's the maximum count value?
  A: 32-bit counters (4,294,967,295 counts)
• Q: Can I use it with 120VAC signals?
  A: No - 0-30VDC only

Warranty & Shipping

• 12-month warranty
• Global express shipping: FedEx, UPS, DHL
• Tracking provided for all orders

Package Contents

• MC-TPIX12 module
• Mounting hardware
• Terminal blocks
• Quick start guide
