TSXDSZ32R5 Modicon Relay Discrete Output Module
Manufacturer:
Schneider
Product No.:
TSXDSZ32R5
Condition:
In Stock
Product Type:
Relay Discrete Output Module
Product Origin:
FR
Weight:
641g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Main Specifications
- Product or Component Type: Discrete output relay module
- Product Range: Modicon TSX Micro automation platform
- Number of Outputs: 32 discrete outputs, screw terminal block
- Contact Type and Composition: Normally Open (NO)
Electrical Specifications
- Output Voltage Limits: 19 to 264 V AC / 10 to 34 V DC
- Conventional Free Air Thermal Current ([Ith]): 2 A
- Response Time: Less than 10 ms
-
Power Consumption (VA):
- 50 VA at 24 V AC, resistive load (12)
- 24 VA at 24 V AC, inductive load (15)
- 100 VA at 48 V AC, resistive load (12)
- 200 VA at 110-120 V AC, resistive load (12)
- 200 VA at 200-240 V AC, resistive load (12)
- 50 VA at 48 V AC, inductive load (15)
- 50 VA at 110-120 V AC, inductive load (15)
- 50 VA at 200-240 V AC, inductive load (15)
-
Power Consumption (W):
- 24 V DC, inductive load (13)
- 24 V DC, resistive load (12)
- Current Consumption: 175 mA
- Power Dissipation: 3.5 W
Insulation and Safety
- Isolation Voltage: 1500 V for 1 second
- Insulation Resistance: Greater than or equal to 10 MOhm
Ordering & Shipping Details
- Category: US1PC1422556
- GTIN: 3389110761573
- Discount Schedule: PC14
- Returnability: Non-returnable
