Touchscreen IC754CKF15CTD GE Fanuc

Overview

The GE Fanuc IC754CKF15CTD QuickPanel is a 15-inch color touchscreen HMI designed for industrial applications. With RS232 and RS485 communication capabilities, it ensures reliable connectivity for control and monitoring systems. Powered by 12V or 24V DC, it features 64 MB of memory for efficient application execution. Its lightweight design and compact dimensions make it an excellent choice for space-limited installations.

Technical Specifications

• Manufacturer: GE Fanuc
• Model: IC754CKF15CTD
• Display: 15-inch color touchscreen for enhanced user experience
• Communication Options: RS232 and RS485, with HMI-CAB-C94 cable compatibility
• Power Supply: Operates on 12 or 24 VDC for versatile usage
• Memory Capacity: 64 MB, ensuring smooth performance for multiple tasks
• Shipping Weight: Approx. 10 lbs
• Dimensions: 16 x 14 x 8 inches, designed for compact panel setups

Application

The IC754CKF15CTD QuickPanel is perfect for industrial automation, process control, and machine interface tasks. Its 15-inch display offers clear visuals for detailed monitoring, while robust communication protocols ensure seamless system integration.

FAQs

• Q1: What is the display size and type of the IC754CKF15CTD?

  • A1: It features a 15-inch color touchscreen for user-friendly operation.
• Q2: What communication protocols are supported?

  • A2: The HMI supports RS232 and RS485 communication standards.
• Q3: What power supply is required?

  • A3: The unit operates on 12 or 24 VDC input power.
• Q4: Is a specific communication cable needed?

  • A4: Yes, it is compatible with the HMI-CAB-C94 communication cable.
