Technical Specifications:
Product Type:
Double-Format PL7 Processor
🔧 Product Model and Type
| Product Model |
TSXP572823M |
| Range of Product |
Modicon Premium Automation Platform |
| Product Type |
Double-format PL7 Processor |
| Software Designation |
PL7 Junior/Pro |
⚡ Electrical and Communication Specifications
| Integrated Connection Type |
RS485 (19.2 kbit/s), Fipio, Ethernet TCP/IP (10/100 Mbit/s) |
| Communication Module Capacity |
1 fieldbus, 4 AS-Interface bus, 1 CANopen |
| Power Consumption |
1180 mA at 5 V DC |
| Memory |
64 Kwords data, 160 Kwords program with PCMCIA |
🔋 I/O and Processing Specifications
| Discrete I/O Capacity |
1024 I/O |
| Analogue I/O Capacity |
80 I/O |
| Number of Racks |
16 racks (4/6/8 slots), 8 racks (12 slots) |
| Processing Speed |
0.19 µs Boolean, 2.6 µs Floating points |
📏 Physical and Environmental Specifications
| Operating Temperature |
0…60 °C |
| Storage Temperature |
-25…70 °C |
| Relative Humidity |
10…95% for operation, 5…95% for storage |
| Operating Altitude |
0...2000 m |
⚙️ Certifications and Standards
| Certifications |
BV, RINA, DNV, RMRS, LR, GL, ABS |
| Standards |
IEC 61131-2, UL 508, CSA C22.2 |
| Protection Degree |
IP20 |
| Pollution Degree |
2 |
📦 Packing and Shipping Details
| Package Type |
PCE |
| Number of Units |
1 |
| Package Height |
9.5 cm |
| Package Width |
18.0 cm |
| Package Length |
26.0 cm |
| Package Weight |
776.0 g |
🔧 New Parameters
| Execution Time (Boolean) |
0.19 µs without PCMCIA, 0.21 µs with PCMCIA |
| System Overhead |
0.35 ms for fast task, 1.2 ms for master task |
| PCMCIA Card Capacity |
2688 Kwords additional data storage |
| Number of Instructions per ms |
4.76 Kinst/ms (100% Boolean without PCMCIA) |
| Local Signaling |
LEDs for Ethernet port status, processor running, fault indicators |
