Schneider Modicon 140NOE77111 Ethernet Network TCP/IP Module
Manufacturer:
Schneider
Product No.:
140NOE77111
Condition:
In Stock
Product Type:
Ethernet Network TCP/IP Module
Product Origin:
France
Weight:
345g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Overview
Brand: Schneider Modicon
Model: 140NOE77111
Type: Ethernet Network TCP/IP Module
Platform: Modicon Quantum Automation Platform
Web Server: Class C30, FactoryCast Configurable
Key Features
- Web Services: Data editor, rack viewer
- Communication Services: Bandwidth management, FDR server, global data, I/O scanning, Modbus TCP messaging, NTP time synchronization, SMTP email notification, SNMP network management
- Redundancy: Hot standby redundant architecture
- Supply: Via the power supply of the rack
Technical Specifications
| Specification | Details |
|---|---|
| Communication Protocol | Ethernet Modbus TCP/IP |
| Physical Interface | MT/RJ 100BASE-FX fiber optic, RJ45 10BASE-T/100BASE-TX twisted pair |
| Transmission Rate | 10/100 Mbit/s |
| Current Consumption | 750 mA @ 5 V DC |
| Module Format | Standard |
| Weight | 0.345 kg |
Local Signaling
| LED Indicators | Description |
|---|---|
| 10 Mbps or 100 Mbps Data Rate (10 MB/100 MB) | Indicates data rate |
| Collision Detection (Coll) | Detects collisions |
| Download Mode (Kernel) | Shows download mode |
| Ethernet Module Fault (Fault) | Indicates Ethernet module fault |
| Ethernet Network Status (RUN) | Shows network status |
| Full-duplex Mode (Fduplex) | Indicates full-duplex mode |
| Module Ready (Ready) | Shows module readiness |
| Network Active (Link) | Indicates network activity |
| Rack Operational (Active) | Indicates rack operational status |
| Transmission/Reception Activity (TxAct/RxAct) | Shows transmission/reception activity |
Environmental Specifications
| Parameter | Value |
|---|---|
| IP Degree of Protection | IP20 |
| Certifications | CUL, UL 508 |
| Standards | CSA C22.2 No 142, FM Class 1 Division 2 |
| Resistance to Electrostatic Discharge | 4 kV contact IEC 801-2, 8 kV on air IEC 801-2 |
| Resistance to Electromagnetic Fields | 10 V/m 80-1000 MHz IEC 801-3 |
| Operating Temperature | 0-60 °C |
| Storage Temperature | -40-85 °C |
| Relative Humidity | 95% without condensation |
| Operating Altitude | ≤ 4500 m |
