Yokogawa SAI143-H63 Module Specifications

Brand: Yokogawa

Model: SAI143-H63

Product Type: Analog I/O Module

• Environmental Conditions:

  • Operating Temperature: -20°C to 70°C
  • Storage Temperature: -40°C to 85°C
  • Humidity: 5% to 95% RH (non-condensing)

• Power Supply Requirements:

  • Voltage Range:
    • 100 to 120 V AC: -15%, +10%
    • 220 to 240 V AC: -15%, +10%
    • 24 V DC: -10%, +20%
  • Frequency: 50/60 Hz ±3 Hz

• Mechanical Specifications:

  • Vibration: Continuous vibration up to 4.9 m/s² (9 Hz to 150 Hz)
  • Impact: 147 m/s² for 11 ms
  • Altitude: Usable up to 2000 meters above sea level

• I/O Signal Specifications:

  • Communication Bus: ESB Bus with a maximum of 13 safety node units connectable
  • Network Speed: 128 Mbits/second
  • Transmission Distance: Up to 10 meters

• I/O Module Types:

  • Analog I/O Modules: Provide input and output capabilities with various ranges and types
  • Digital I/O Modules: Handle input and output of binary signals
  • Communication Modules: Support serial and Ethernet communications

• Safety and Compliance:

  • Insulation Resistance: 20 MΩ at 500 V DC
  • Withstanding Voltage: 1500 V AC for 1 minute
  • Noise Immunity: Electric field 10 V/m (80 MHz to 1 GHz)
  • Electrostatic Discharge: 4 kV (direct), 8 kV (indirect)

• Miscellaneous:

  • Corrosive Gas: Compliant with ANSI/ISA S71.04 G3 standards
  • Dust Limit: Maximum of 0.3 mg/m³
