Honeywell FS-TSDO-04UNI Safe Digital Output Module

The Honeywell FS-TSDO-04UNI is a high-performance safety digital output module designed for critical applications. This reliable module provides eight isolated output channels with fast response times.

Technical Specifications

• Brand: Honeywell
• Model: FS-TSDO-04UNI
• Output Channels: 8 isolated digital outputs
• Output Type: Solid state
• Nominal Voltage: 24VDC
• Voltage Range: 18-32VDC
• Max Current per Channel: 0.5A
• Max Total Current: 4A
• Response Time: ≤1ms (on/off)
• Power Supply: 24VDC nominal
• Power Consumption: <8W
• Isolation: 500VDC channel-to-channel, 1500VDC to backplane
• Operating Temperature: -20°C to 60°C
• Storage Temperature: -40°C to 85°C
• Dimensions: 38x174x138mm
• Weight: 550g

Packaging Contents

• One Honeywell FS-TSDO-04UNI Safety Module
• Installation manual and documentation
• Mounting accessories and hardware
• Shipped via FedEx, UPS, or DHL

Frequently Asked Questions

• What safety certifications does this module have?
  The module meets SIL 2 and SIL 3 safety integrity levels.
• Can I use all eight channels at maximum current simultaneously?
  Yes, but total current must not exceed 4A across all channels.
• What is the minimum load current for reliable operation?
  The module requires a minimum load of 5mA per channel.
• Does this module support hot swapping?
  Yes, it supports removal and insertion under power.
• What type of loads can I connect to the outputs?
  You can connect resistive, inductive, and lamp loads.
