Profibus Communication Module SST-PB3-CLX-RLL

Profibus Communication Module SST-PB3-CLX-RLL

Technical Specifications:

Manufacturer:
Allen-Bradley
Product No.:
SST-PB3-CLX-RLL
Condition:
In Stock
Product Type:
Profibus Communication Module
Product Origin:
USA
Weight:
430g
Shipping port:
Xiamen
Warranty:
12 months

⚡ Product Overview

Part Number SST-PB3-CLX-RLL
Manufacturer Molex
Product Type SST PB3 In Chassis Module
Compatible Series 1756 ControlLogix; Honeywell PlantScape

🔧 Module Specifications

Module Type Profibus Communication Module
Slot Width Single slot
Module Location Any slot
Backplane Current 850 mA @ 5 VDC; 1.75 mA @ 24 VDC

📦 Connection & Network

Embedded Ports One (1) 9-pin sub-D connector
Transmission Speed 9600, 19200, 31.25k, 45.45k, 93.75k, 187.5k, 500k, 1.5M, 3M, 6M, 12Mbaud
Port Type PROFIBUS D-Sub Female (9 pin)
Channel 1

⚙️ Performance Specifications

No. of DP Slaves Supported Up to 125
Supported I/O Modules Up to 256
Input Data Words 122 Words
DPV0 Slave Function Supported

💡 Key Features

Maximum Modules per Rack 8 modules
Network Connection Type PROFIBUS D-Sub Female (9 pin)
Weight 430 g
Applicable Allen-Bradley Series ControlLogix

🔍 Additional Specifications

Operating Temperature 0°C to 60°C
Storage Temperature -40°C to 85°C
Power Consumption Max. 5 Watts
Compliance CE, UL, cUL Certified
