PFXGP4501TAD Proface Touch Panel HMI
Manufacturer:
Schneider
Product No.:
PFXGP4501TAD
Condition:
In Stock
Product Type:
Touch Panel HMI
Product Origin:
FR
Weight:
2000g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🌐 Basic Product Information
| 🛠️ Feature | Details |
|---|---|
| Type | Programmable Human-Machine Interface (HMI) |
| Series | GP4000 Series |
| Display Size | 10" |
| Model | PFXGP4501TAD |
| Global Code | PFXGP4501TAD |
🔧 Display Specifications
| 📺 Feature | Details |
|---|---|
| Display Type | TFT True Color LCD |
| Display Size | 10.4" |
| Resolution | 640 x 480 pixels (VGA) |
| Effective Display Area | W211.2 x H158.4 mm |
| Display Colors | 65,536 colors (no flicker) / 16,384 colors (flicker) |
| Backlight | White LED (non-replaceable by the user) |
| Backlight Life | Over 50,000 hours |
| Brightness Adjustment | 16 levels adjustable |
| Touch Panel Type | Resistive (Analog) |
| Touch Panel Resolution | 1,024 x 1,024 |
| Touch Panel Life | Over 1,000,000 touches |
🌡 Electrical Specifications
| 🔌 Feature | Details |
|---|---|
| Input Voltage | 24 Vdc |
| Rated Voltage | 19.2~28.8 Vdc |
| Voltage Drop | Less than 10 ms |
| Power Consumption | Less than 17W |
| Surge Current | Less than 30 A |
| Interference Resistance |
|
| Insulation Strength | 1,000 Vac, 20 mA for less than 1 minute |
| Insulation Resistance | 500 Vdc, 10 MΩ or more |
| Dimensions | W272.5 x H214.5 x D57 mm |
| Weight | Less than 2 kg |
