Panasonic MSDB045A1A11 Servo Drive

Technical Specifications

• Power Supply: AC 200V, 1-phase or 3-phase
• Rated Power: 400 W
• Rated Current: 2.7 A
• Control Method: PWM (Pulse Width Modulation) Control
• Motor Compatibility: Designed for use with Panasonic A-series servo motors
• Communication Interface: RS-232C/RS-485
• Maximum Speed: Up to 4500 RPM
• Torque Control: Yes, with high torque accuracy
• Feedback System: Incremental encoder
• Ambient Temperature Range: 0°C to 40°C
• Protection Class: IP20
• Dimensions: 150 mm x 80 mm x 170 mm
• Weight: Approx. 1.5 kg
