Technical Specifications

• Model Number: P0926KE
• Baseplate Type: Dual-slot with integrated time strobe function
• Number of Slots: 2 slots for FCMs (Field Control Modules)
• Voltage Rating: 24V DC (nominal)
• Current Rating: 2A (per slot)
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Humidity Range: 5% to 95% (non-condensing)
• Mounting Type: Rack or panel-mounted for easy integration
• Dimensions: 300 mm x 120 mm x 50 mm (L x W x H)
• Weight: 0.8 kg (approximately)
• Strobe Pulse Rate: Configurable, typically 1 to 100 ms depending on the application
• Shock Resistance: 15g, 11 ms pulse in each axis
• Vibration Resistance: 1g at 10 to 150 Hz
• Connection Type: Multi-pin connectors for communication with control modules
• Enclosure Protection: IP20-rated for indoor use
• Certifications: CE, UL, and ATEX compliant for use in industrial environments
