Technical Specifications

• Model Number: P0926JC
• Base Material: Industrial-grade plastic with metal components for high durability
• Mounting Type: DIN-rail or panel-mounted
• Operating Voltage: 24V DC (typical)
• Current Rating: 5A per channel
• Dimensions: 100 mm x 80 mm x 30 mm (L x W x H)
• Weight: 0.3 kg (approximately)
• Connection Type: Clamp-style terminals for secure field wiring
• Operating Temperature: -20°C to +70°C
• Storage Temperature: -40°C to +85°C
• Humidity: 5% to 95% RH (non-condensing)
• Vibration Resistance: 2g at 10 to 150 Hz
• Shock Resistance: 10g for 11 ms
• Certifications: CE, ATEX, and IECEx certified for use in hazardous locations
• Enclosure Protection: IP20 rating for indoor industrial environments

Additional Parameters

• Wire Size Compatibility: Supports wire sizes from 0.5 mm² to 2.5 mm² (AWG 20-14)
• Channel Capacity: Up to 16 individual connections
• Insulation Resistance: 100 MΩ at 500 V DC
• Power Consumption: Less than 2W, ensuring energy efficiency in large systems
• Response Time: < 15 ms, allowing for fast data transmission and real-time process control
• Grounding Method: Includes integrated grounding points for safety and signal integrity
• Diagnostic Features: Features self-check mechanisms to monitor connection status and integrity
• Safety Standards: Compliant with RoHS and WEEE directives for environmental safety
