Technical Specifications

• Processor: Atom E3815, 1.46 GHz
• Memory:
  • Main: 256 MB with ECC
  • Static RAM: 2 MB with ECC, backed by a battery
• Secondary Storage: 1 GB onboard flash memory
• External Media: 1 SD card slot supporting SDHC (4 to 32 GB), Class 10
• Serial Port: 1 RS-232-C port, D-sub 9 pins, male
• Communication Method: Full/Half duplex (software settings), asynchronous
• Baud Rate: 0.3, 1.2, 2.4, 4.8, 9.6, 14.4, 19.2, 28.8, 38.4, 57.6, or 115.2 kbps
• Network Interface: 2 Ethernet ports, RJ45 modular jacks (1000BASE-T, 100BASE-TX, 10BASE-T)
• I/O Interface: SB bus (duplex)
• Battery: 1000 mAh graphite fluoride lithium battery
• Display: 3 LEDs for CPU status, 2 LEDs for Ethernet, 1 SD LED, and 1 EXEC LED
• Switches: RESET, SHUT DOWN, FUNC, EXEC
• Protection: CPU cover with a hole for a wire lock
• Power Supply: 5 V DC ±5%, Max. 1200 mA current consumption
• Dimensions (W x H x D): 65.8 x 130 x 149.3 mm
• Weight: 0.9 kg
• Occupying Slots: 2
