Technical Specifications:
Product Type:
Position Control Module
🔧 Technical Specifications
| 📋 Parameter |
🌡 Details |
| Model |
MVP50 369B1848G5007 |
| Operating Voltage |
21.6 - 26.4 VDC |
| Power Consumption |
11.0 W |
| Torque Output |
0.79 N-m |
| Control Type |
Valve position control |
| Input Power |
24 VDC (±10%) |
| Current Consumption |
<100 mA (typical) |
| Output Range |
- 4-20 mA
- 0-10 VDC (configurable)
|
| Resolution |
0.1% of full scale |
| Accuracy |
±0.5% of full scale |
| Response Time |
< 50 ms |
| Operating Temperature Range |
-20°C to +70°C (-4°F to +158°F) |
| Storage Temperature Range |
-40°C to +85°C (-40°F to +185°F) |
| Humidity |
5% to 95% non-condensing |
| Protection Rating |
IP65 (Dust-tight and protected against water jets) |
| Communication Protocols |
- Modbus RTU
- Profibus DP
- HART (optional)
|
| Mounting |
DIN Rail or Panel Mount |
| Dimensions |
150 mm x 75 mm x 50 mm (L x W x H) |
| Weight |
450 g |
