MTL5041 - MTL Repeater Power Supply
Manufacturer:
MTL
Product No.:
MTL5041
Condition:
In Stock
Product Type:
Repeater Power Supply
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🔌 Product Overview
| Part Number | MTL5041 |
| Manufacturer | MTL |
| Product Type | Repeater Power Supply |
| Number of Channels | One |
🌍 Safe and Hazardous Area Specifications
| Transmitter Location | Zone 0, IIC, T4–6 hazardous area if suitably certified; Div. 1, Group A |
| Safe-area Output Signal Range | 4 to 20mA |
| Over/Under-range | 0 to 24mA |
| Load Resistance | 0 to 1kΩ |
| Ripple | <125µA peak-to-peak |
| Hazardous-area Input Signal Range | 0 to 24mA |
| Transmitter Voltage | 16.5V at 20mA |
📈 Performance Characteristics
| Transfer Accuracy at 20°C | Better than 20µA (typically 5µA) |
| Temperature Drift | <1µA/°C |
| Response Time | Settles within 10% of final value within 250µs |
| LED Indicator | Green: Power indication |
🔋 Power and Safety
| Supply Voltage | 20 to 35V dc |
| Maximum Current Consumption | 70mA at 24V, 85mA at 20V, 55mA at 35V |
| Power Dissipation | 1.2W at 24V |
| Safety Description | 28V, 300Ω, 93mA; Um = 250V rms or dc |
