MTL4573 MTL | Temperature Converter
Manufacturer:
MTL
Product No.:
MTL4573
Condition:
In Stock
Product Type:
Temperature Converter
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
MTL Product Information |
|
|---|---|
| Product Type: | MTL4573 |
MTL Calibration Accuracy (at 20°C) |
|
|---|---|
| Inputs: | mV/THC: ± 15µV or ± 0.05% of input value (whichever is greater) Pt 100 - RTD: ± 80mΩ |
| Output: | ± 11µA |
MTL Temperature Drift (Typical) |
|
|---|---|
| Inputs: | mV/THC: ± 0.003% of input value/°C Pt 100 - RTD: ± 7mΩ/°C |
| Output: | ± 0.6µA/°C |
MTL Example of Calibration Accuracy and Temperature Drift (RTD Input) |
|
|---|---|
| Span: | 250Ω |
| Accuracy: | ± (0.08/250 + 11/16000) x 100% = 0.1% of span |
| Temperature Drift: | ± (0.007/250 x 16000 + 0.6) µA/°C = ±1.0µA/°C |
MTL Safety Features |
|
|---|---|
| Safety Drive on Sensor Failure: | Upscale, downscale, or off |
| Early Burnout Detection (EBD): | For thermocouples (when selected); indicated when loop resistance increase is > 50Ω |
MTL Output Range |
|
|---|---|
| Output Range: | 4 to 20mA nominal into 600Ω max. |
| Out of Range Characteristic: | MTL or NAMUR NE43 |
| Maximum Lead Resistance (THC): | 600Ω |
| Response Time: | Typical 500 ms |
MTL LED Indicator |
|
|---|---|
| Green: | EBD alarm indication, power, and status indication |
| Yellow: | Alarm indication |
MTL Power Requirements and Dissipation |
|
|---|---|
| Maximum Current Consumption (with 20mA Signal): | 50mA at 24V |
| Power Dissipation within Unit (with 20mA Signal): | 1.2W at 24V |
MTL Safety Description |
|
|---|---|
| Safety Description: | Refer to certificate for parameters. Um=253V rms or dc |
MTL RTD Excitation and Compensation |
|
|---|---|
| RTD Excitation Current: | 200µA nominal |
| Cold Junction Compensation, THC Input: | Selectable ON or OFF |
| Cold Junction Compensation Error: | ≤ 1.0°C |
MTL Signal Rejection |
|
|---|---|
| Common Mode Rejection: | 120dB for 240V at 50Hz or 60Hz |
| Series Mode Rejection: | 40dB for 50Hz or 60Hz |
