MBDKT2510E Panasonic Family Servo Drive

Technical Specifications

• Model Number: MBDKT2510E
• Series: MINAS A5ⅡE
• Control Type: Position control
• Power Supply:
  • DC Voltage: 24 V / 48 V
  • AC Voltage: 100 V / 200 V / 400 V
• Power Output: 10 W to 7.5 kW (depending on the motor)
• Encoder Support:
  • 20-bit incremental encoder
  • 17-bit absolute/incremental encoder
• Response Frequency: 2.3 kHz
• Operating Temperature: 0°C to 50°C
• Storage Temperature: -20°C to 65°C
• Humidity Range: 5% to 90% relative humidity, non-condensing
• Protection Rating: IP20
• Maximum Rated Current for Power Element: 15 A
• Rated Current for Current Detector: 10 A
• Power Supply Voltage:
  • Main Power Supply: Single-phase/three-phase 200 V (+10% -15%) ~ 240 V (+10% -15%), 50/60 Hz
  • Control Power Supply: Single-phase 200 V (+10% -15%) ~ 240 V (+10% -15%), 50/60 Hz
• Dimensions (W x H x D): 55 mm x 150 mm x 130 mm
• Weight: 1.0 kg
