LG1093AA46 Honeywell - Flame Detector

LG1093AA46 Honeywell - Flame Detector

Technical Specifications:

Manufacturer:
Honeywell
Product No.:
LG1093AA46
Condition:
In Stock
Product Type:
Flame Detector
Product Origin:
USA
Weight:
2000g
Shipping port:
Xiamen
Warranty:
12 months

Honeywell LG1093AA46 Flame Detector

Features and Specifications

  • UV radiation detection range: 180-260 nm
  • Solar blind and resistant to black body radiation
  • Temperature range: -40 to 176°C
  • High sensitivity with a fast flame response time of 0.1 seconds
  • Flame loss response time: 0.2 seconds maximum
  • Operational distance up to 330 meters (1000 feet) from sensor to amplifier

Amplifier Compatibility

  • EG1033AA: Transistor open collector output
  • EG1033AB and EG1033AC: Relay contacts (SPDT)
  • Supports multiple voltage requirements: 28 Vdc, 20-35 Vdc, and 115 Vac

Durability and Reliability

The LG1093AA46 Flame Detector boasts a two-year shelf life and a mean time between failures (MTBF) of 10,000 hours. It has accumulated over one billion operating hours, underscoring its reliability and durability in demanding environments.

Approvals and Certifications

  • CE Mark for EMC 89/336/EEC and LVD 73/23/EEC
  • ATEX Explosive Atmosphere 94/9/EC (EEx d IIA T3 or EEx d IIC T3, Zone 1 and 2)
  • Factory Mutual approval for explosive atmospheres (Class I, Div 1 and 2, Groups B, C, and D)

Technical Details

Parameter Details
Sensor Geiger Mueller-type phototube
Mounting 3/4 inch internal NPT
Cable Teflon shielded, 61 feet (12.8 meters) in length
Viewing window Rated for 10 bar (150 psi)
Shipping weight 2 kg
Cross Reference GE 261A1812P15
