LG1093 Flame Detector | LG1093AC02 Honeywell
LG1093 Flame Detector | LG1093AC02 Honeywell
Technical Specifications:
Manufacturer:
Honeywell
Product No.:
LG1093AC02
Condition:
In Stock
Product Type:
Flame Detector
Product Origin:
USA
Weight:
2000g
Shipping port:
Xiamen
Warranty:
12 months
Flame Detector LG1093AC02 Honeywell
Specifications
- Shipping Weight: 2.0 KG
- Amplifiers support multiple voltage requirements: 28 Vdc, 20-35 Vdc, and 115 Vac
- Operating distances up to 330m (1000ft), sensor to amplifier
- Qualified component on General Electric turbines
Certifications
- Available with European Directive CE mark for EMC 89/336/EEC, LVD 73/23/EEC, and ATEX Explosive Atmosphere 94/9/EC (EEx d IIA T3 or EEX d IIC T3, Zone 1 and 2)
- Available with Factory Mutual approval for explosive atmospheres (Class I, Div 1 and 2, Groups B, C, and D)
Technical Details
- Flame Sensor with 3/4 inch internal NPT mounting and Teflon shielded cable with 1" external conduit thread
- Viewing window rated for 10bar (150psi)
- Mounting Interface: 1.73 inch O.D by 0.14 inch wide flange
- Control Panel Connection: Two connector armored cable
- Operating Temperature: -40F to +350F
- Window Pressure Rating: 6.3 psig
- Model: Cable length 9ft (2.7m)
- Supply voltage: No
- Approvals: CE/ATEX (EEx d IIA T3)
