IMRIO02 ABB Bailey Remote IO Module
Manufacturer:
ABB
Product No.:
IMRIO02
Condition:
In Stock
Product Type:
Remote IO Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Power Requirements and Specifications
| Parameter | Specification |
|---|---|
| Operating Voltage and Current |
+ 5 VDC: 1.45 amps typ., 1.80 amps max. + 15 VDC: 17.5 mA typ., 20 mA max. - 15 VDC: 80.0 mA typ., 90 mA max. |
| Consumption |
+ 5 VDC: 7.25 watts typ., 9.0 watts max. + 15 VDC: 0.26 watts typ., 0.30 watts max. - 15 VDC: 1.20 watts typ., 1.35 watts max. |
| Data Rates | Serial Link: 1 Mbit/sec |
| Memory Capacity |
Static RAM: 8 kbytes (shared with MFP) ROM: 32 kbytes |
| Mounting | Uses one slot in Infi 90 Module Mounting Unit. |
| Environmental |
Ambient Temperature: 0°C to 70°C (32°F to 158°F) Relative Humidity: 5% to 90% RH (± 5%) up to 55°C (131°F) non-condensing 5% to 40% (± 5%) at 70°C (158°F) non-condensing Atmospheric Pressure: Sea level to 3 km (1.86 miles) Air Quality: Non-corrosive |
