IC698RMX016 GE Fanuc | Redundancy Memory Xchange Module

IC698RMX016 GE Fanuc | Redundancy Memory Xchange Module

Technical Specifications:

Manufacturer:
GE
Product No.:
IC698RMX016
Condition:
In Stock
Product Type:
Redundancy Memory Xchange Module
Product Origin:
USA
Weight:
370g
Shipping port:
Xiamen
Warranty:
12 months

Product: IC698RMX016

Brand: GE Fanuc

Origin: USA

Description: The IC698RMX016 is a Redundancy Memory Xchange Module designed for the GE Fanuc RX7i PACsystem. This module facilitates the exchange of 16MB redundant memory and is conformally coated for enhanced durability.

Technical Specifications:

Parameter Specification
Physical Size PCB: 6.299” W x 9.187” H
Memory 16MB SDRAM
Operating Voltage +5VDC (from power supply)
Current Requirements 1.8A
Connectors - Fiber optic LC type, conforms to IEC 61754-20
- Zirconium ceramic ferrule
- Insertion Loss: 0.35 dB (maximum)
- Return Loss: -30dB
Temperature Range -20°C to +85°C



Installation:

  • Must be installed in the main (Rack 0) RX7i rack, preferably in slots 3 and 4.
  • Ensure rack power is off during installation.
  • Connect cables to TX and RX connectors and route the fiber optic cable accordingly.
  • Power on the RX7i rack after installation.

Configuration: The module requires a hardware configuration from the RX7i CPU to operate on a network. Parameters such as Node ID, Redundant Transfer Mode, Rogue Master, Network Memory Offset, and Interrupt enable can be configured for general-purpose reflective memory operation.

Ordering Information:

  • Redundancy Memory Xchange Module for RX7i: IC698RMX016
  • Control Memory Xchange Module for RX7i: IC698CMX016
  • Fiber Optic Cables: VMICBL-000-F5-0XX (where 0XX denotes different lengths)
  • RX7i VME 700MHz CPU with Redundancy: IC698CRE020
  • Lithium Battery Pack: IC698ACC701
  • Rack Fan Assembly:
    • 120VAC: IC697ACC721
    • 240VAC: IC697ACC724
    • 24VDC: IC697ACC744
  • RX7i PLC Power Supply:
    • 100 watt: IC698PSA100
    • 350 watt: IC698PSA350
  • RS-232 Cable: IC200CBL001
