IC697ALG320 Module Specifications

Brand: GE Fanuc

Model: IC697ALG320

Product Type: Analog Input Module

 Series: Series 90-70

Configurable Features

• Voltage/Current Options:

  • The default setting is -10V to +10V.
  • Other selectable ranges include 0V to +10V, -5V to +5V, and 0V to +5V.
  • The module also supports current input from 4 mA to 20 mA.

• Fault Reporting:

  • Fault reporting can be enabled or disabled for each channel, with the default setting enabled.

• Scaling Points:

  • Users can set scaling points for current up to 32767 µA, with default values of +20000 µA to -4000 µA.
  • For voltage, the scaling can be set up to 10000 mV, with default points set at +10000 mV to -10000 mV.

• Output Default:

  • The default output state for channels is set to Off.

• Default Value:

  • Each channel has a configurable default value set at 0, which can be set up to 32767.
