Technical Specifications

Compatibility

• PLC Compatibility: Designed for use with GE Fanuc Series 90-70 PLC systems.
• Hardware Integration: Compatible with other GE Fanuc automation components for seamless system integration.

Components

• Hardware Components:
  • Compensation module or card.
  • Temperature sensors or compensating devices (depending on the application).
  • Wiring and connectors for integration.
• Software:
  • Programming Tools: Includes software for configuring and programming compensation parameters.
  • Diagnostic Software: Tools for monitoring the system’s performance post-compensation.

Input/Output Specifications

• Input Type:
  • Typically uses analog or digital inputs for reading system performance or environmental conditions (e.g., temperature).
• Output Type:
  • Provides corrected signals to the system’s control or measurement processes, ensuring accurate outputs.

Environmental Specifications

• Operating Temperature:
  • 0°C to 60°C (32°F to 140°F).
• Storage Temperature:
  • -40°C to 85°C (-40°F to 185°F).
• Humidity:
  • 5% to 95% RH, non-condensing.

Electrical Specifications

• Voltage:
  • 24V DC (nominal).
• Current:
  • Typically 150mA to 250mA at 24V DC, depending on system configuration.
• Power Consumption:
  • Maximum 6W under full load conditions.

Physical Specifications

• Dimensions:
  • Width: 3.0 inches (76.2 mm).
  • Height: 6.5 inches (165.1 mm).
  • Depth: 5.0 inches (127.0 mm).
• Weight: 0.6 kg (1.3 lbs).

Compliance

• CE Marked: Yes, compliant with European Union standards.
• UL Listed: Yes, meets UL safety regulations.
