Technical Specifications:
Product Type:
Voltage Output Module
Manufacturer
GE Fanuc
Product Details
| Product No. |
IC694MDL940 |
| Product Type |
PACSystems RX3i AC/DC Voltage Output Module |
| Module Type |
Discrete Output |
Backplane
| Backplane Support |
No Backplane Restrictions |
| Number of Slots Module Occupies on Backplane |
1 |
Electrical Specifications
| Output Voltage Range |
0 to 125 VDC, 5/24/125 VDC nominal; 0 to 265 VAC (47 to 63 Hz), 120/240 VAC nominal |
| Number of Points |
16 |
| Load Current per Point |
2 A |
| Response Time (ms) |
15 on/15 off |
| Output Type |
Relay |
| Points per Common |
4 |
Connector and Groups
| Connector Type |
Terminal Block (20 screws), included with module |
| Number of Groups |
Four (4) |
| Switching Current |
2.0 Amps |
| Number of Channels per Group |
Four (4) |
| Maximum Backplane Draw |
135 Milliamps |
| Rated Voltage |
24 VDC; 120/240 VAC |
| Inrush Rating |
5.0 Amps |
| Maximum Response Time |
15 Milliseconds |
| Minimum Load |
10 mA |
| Internal Power Used |
7 mA @ 5 VDC; 135 mA @ 24 VDC Relay |
Weight
| Module Weight |
0.45 Kg |
| Shipping Weight |
1.5 Kg |
