GE Fanuc IC693MDL330: Heavy-Duty Output Module for Series 90-30 PLC Systems

Industrial Power Control

• 8-channel AC output module for industrial automation
• Handles high-power loads up to 240V AC / 2A per point
• Designed for GE Fanuc Series 90-30 PLC systems
• Robust isolation protects control systems

Technical Specifications

• Brand/Model: GE Fanuc IC693MDL330
• Output Type: 8-point TRIAC switching
• Voltage Range: 85-264V AC (50/60Hz)
• Current Rating: 2A per point / 4A per group
• Response Time: 1ms ON / 8ms OFF (½ cycle)
• Isolation: 1500V between field/logic sides
• Leakage Current: <5mA @240V AC
• Inrush Handling: 20A surge capacity

Robust Performance

• Industrial-grade 1500V isolation protection
• Wide voltage tolerance (±15% of nominal)
• Low 1.5V voltage drop at full load
• 100mA minimum load current capability
• Compact design: 0.45kg weight

Easy Integration

• Hot-swappable module design
• Tool-free terminal connections
• LED status indicators for each channel
• Compatible with all Series 90-30 racks

Package & Support

• Warranty: 12-month manufacturer coverage
• Shipping: FedEx/UPS/DHL global options
• Includes installation guide
• CE and UL certified

Industrial Applications

• Motor starter control circuits
• HVAC system power management
• Industrial lighting control
• Conveyor system actuators

Technical FAQs

• Q: Maximum group current at 40°C?
  A: 4A across four outputs
• Q: Minimum load requirement?
  A: 100mA per output channel
• Q: Surge current tolerance?
  A: 20A for one AC cycle
• Q: Isolation voltage rating?
  A: 1500V between field and logic sides
• Q: Off-state leakage current?
  A: <5mA at 240V AC
