GE Fanuc IC693MDL310 Series 90-30 Output Module: 12-Channel AC Power Control

Product Highlights

• Industrial-grade 12-channel AC output module for 120V control
• Designed for Series 90-30 PLC systems with fast 1ms response
• Grouped outputs with 500V isolation between groups
• Compact design with LED status indicators for each channel

Technical Specifications

• Brand: GE Fanuc
• Model: IC693MDL310
• Output Type: 120V AC
• Channels: 12 isolated outputs
• Current Rating:
  • 0.5A per point
  • 1A per group @140°F
  • 2A per group @122°F
• Response Time: 1ms ON, ½ cycle OFF

Electrical Characteristics

• Voltage Range: 85-132V AC
• Frequency: 50/60Hz
• Inrush Current: 5A (one cycle)
• Isolation:
  • 1500V field-to-logic
  • 500V between groups

Physical & Environmental

• Dimensions: 5.1cm × 12.7cm × 12.7cm (2" × 5" × 5")
• Weight: 0.3kg (11oz)
• Operating Temp: Up to 140°F (60°C)
• Industrial metal housing

Installation & Diagnostics

• Tool-free mounting in Series 90-30 racks
• 6 LED indicators for output status
• Keyed connectors for safe wiring
• Hot-swappable design

Package & Support

• Includes: IC693MDL310 module
• 12-month manufacturer warranty
• Global shipping via FedEx, UPS, DHL

Industrial Applications

• Motor starter control
• Solenoid valve operation
• Lighting control systems
• Conveyor control circuits

FAQ

• Q: What's the maximum load per channel?
  A: 0.5A continuous per point (higher in grouped operation)
• Q: Does this module support DC voltages?
  A: No, designed exclusively for 85-132V AC operation
• Q: How many status indicators are provided?
  A: Features 6 LED indicators for output monitoring
