IC670MDL331 Field I/O control GE Fanuc
Manufacturer:
GE
Product No.:
IC670MDL331
Condition:
In Stock
Product Type:
Field I/O control
Product Origin:
USA
Weight:
2000g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Overview:
The GE Fanuc IC670MDL331 is an 8-channel discrete output module designed for controlling AC loads in industrial applications. Featuring robust isolation, precise control, and integrated protection, it is suitable for various automation tasks requiring 120 VAC output signals.
Technical Specifications:
| Parameter | Details |
|---|---|
| Manufacturer | GE Fanuc |
| Part Number | IC670MDL331 |
| Series | Field Control |
| Product Type | Discrete Output Module |
| Rated Voltage | 120 VAC |
| Output Voltage Range | 85–132 VAC |
| Number of Channels | 8 |
| Output Current (Per Point) | 2 A (maximum) |
| Output Current (Per Module) | 6–8 A (maximum) |
| Inrush Current | 20 A (maximum for one cycle) |
| Output Voltage Drop | 3 V (maximum) |
| Output Impedance | 3 kΩ (typical) |
| Isolation Voltage | 1500 VAC for 1 minute; 250 VAC continuous |
| Current Drawn from BIU | 154 mA (maximum) |
| Response Time (On) | 1 ms (maximum) |
| Response Time (Off) | ½ cycle (maximum) |
| Output Grouping | 4 groups of 2 outputs |
| Output Data | 8 discrete outputs |
| Protection Mechanisms | Fuse: 3 A, 250 V; RC snubber: R=47.5 Ω, C=0.022 µF |
