IC670ALG320 GE Fanuc Field Control Analog Output Module
Manufacturer:
GE
Product No.:
IC670ALG320
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
USA
Weight:
250g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | IC670ALG330 |
| Manufacturer | GE Fanuc |
| Series | Field Control / Field I/O Control |
| Nominal Supply Voltage | 24 VDC |
| Output Data Format | 4 words |
| Current Output Range | 4-20 mA |
| Voltage Output Range | 0-10 VDC |
| ADC Conversion Resolution | 12 bits |
| Digital Resolution | 12 bits, typical |
| Current Draw (Standby) | 80 mA |
| Current Draw (Operating) | 180 mA (including loop current) |
| Maximum Current Draw from BIU Power Supply | 51 mA |
| Isolation Ratings | Ground to Logic Isolation: 1500 VAC for 1 minute; 250 VAC continuous Isolation: 1500 VAC for 1 minute; 250 VAC continuous |
| Temperature Coefficient | ±0.002% of value per °C (typical), ±0.005% of value per °C (maximum) |
| Linearity | 1 LSB resolution value |
| Module Power Dissipation | Minimum: 1.4 Watts Maximum: 4.3 Watts |
| External Power Supply Requirement | 20-29 VDC, with a maximum ripple of 5% |
| Conversion Time | 60 microseconds per channel (typical) at a 1 MHz clock |
