GE IS200ICBDH1ABB Printed Circuit Board
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Description
The IS200ICBDH1ABB (ICBD) is a Printed Circuit Board originally manufactured by GE, now discontinued and somewhat challenging to locate.
Components
The ICBD comprises a variety of components:
- 61 capacitors
- 10 diodes
- 3 transformers
- 4 transistors
- 95 resistors
- 15 integrated circuits
- 1 fuse
- 1 inductor coil
Ports and Connectors
The board features:
- An 8-pin female circular port
- An RS-232 female 9-pin port
- Four labeled ethernet jacks: J12A, J12B, J11A, J11B
- Three black pin connectors with 40, 10, and 26 pins respectively, with a white 9-pin male connector between the 40 and 26-pin connectors
- Three white 96-pin female ports
- Four stab-on connectors labeled CHAS 1, CHAS2, CCOM 2, and CCOM1
Mounting and Connection
Factory-drilled holes in the board's corners facilitate mounting, with two terminal screws available for wire connection. The part number label is positioned on the left side of the board near the fuse. The ICBD can be connected to a metallic chassis (sold separately), which can then be mounted alongside other PCBs within a rack.
