GE HE693THM449 Thermocouple Input Module

Features

• Thermocouple Types Supported: J, K, N, T, E, R, S
• Resolution: 0.5°C
• Accuracy: ±0.5°C (typical for Type J)
• Common Mode Rejection: >100dB
• Common Mode Range: ±12V
• Maximum Safe Overload: ±35V
• Module Update Rate: 45 channels per second
• Input Impedance: >20MΩ
• A/D Conversion Type: Integrating
• A/D Conversion Time: 5 ms
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Relative Humidity: 5% to 95% non-condensing

Technical Specifications

• Power Consumption: 70mA @ 5VDC, 60mA @ 24V Relay
• Number of Channels: 4
• I/O Points Required: 4% AI [16% I]
• ALARM BITS: 0.25kg
