IC697PWR711 Power Supply Module Specifications

Brand: GE Fanuc

Model: IC697PWR711

Product Type: Power Supply Module

Features:

• Operation Voltage: 120/240 VAC, or 125 VDC
• Output Power: 100 watts total
• Output Voltages:
  • +5 VDC up to 20 amps
  • +12 VDC up to 2 amps
  • -12 VDC up to 1 amp

Specifications:

• Nominal Rated Voltage: 120/240 VAC or 125 VDC
• Input Voltage Range:
  • AC Input: 90 to 264 VAC, 47 to 63 Hz
  • DC Input: 100 to 150 VDC
• Input Power: 135 watts (typical), 160 watts (maximum)
• Input Half Cycle Peak Inrush: 3 amps (typical)
• Power Factor: Greater than 0.93
• Output Power: 100 watts maximum (total for all 3 outputs)
• Output Voltage Ranges:
  • +5 VDC: 4.90 to 5.25 volts (5.07 volts nominal)
  • +12 VDC: 11.75 to 12.6 volts
  • -12 VDC: -12.6 to -11.75 volts
• Overvoltage Limit: +5 VDC Output: 5.7 to 6.7 volts
• Overcurrent Limit:
  • +5 VDC output: 21A (typical)
  • +12 VDC output: 3.5A (typical)
  • -12 VDC output: 1.6A (typical)
• Holdup Time: 21 milliseconds minimum (from loss of AC input)
• Operating Temperature: 0°C to 60°C (32°F to 140°F)
• Storage Temperature: -40°C to +85°C (-40°F to +185°F)
• Weight: 0.22 kg
