Frequency Converter | ACS550-01-059A-4 ABB

In stock
Manufacturer:
ABB
Product No.:
ACS550-01-059A-4
Condition:
In Stock
Product Type:
Frequency Converter
Product Origin:
DE
Weight:
26000g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

ABB Technical Specifications

Global Commercial Alias ACS550-01-059A-4
Product ID 3AUA0000002546-D
ABB Type Designation ACS550-01-059A-4
Product Name Frequency Converter
Catalog Description ACS550-01-059A-4, 59A, 380V, IP21
Country of Origin Germany (DE)
Customs Tariff Number 85044099
Invoice Description ACS550-01-059A-4, 59A, 380V, IP21

ABB Electrical Data

Temp Class 50/60 Hz
Frequency 50/60 Hz
Voltage 380-480 V
Power 30.00 kW
Current 59.00 A

ABB Ordering

Made To Order No
Minimum Order Quantity 1 piece
Order Multiple 1 piece
Quote Only No
Selling Unit of Measure piece

ABB Dimensions

Product Net Weight 26 kg
Product Net Depth / Length 800 mm
Product Net Height 410 mm
Product Net Width 310 mm
Package Depth / Length 800 mm
Package Height 400 mm
Package Width 300 mm

ABB Technical

Number of Phases 3
Degree of Protection IP21
Enclosure Type NEMA Type1
Frequency (f) 47.5 ... 63 Hz
Frame Size R4
Input Voltage (Uin) 380 … 480 V
Mounting Type Wall-mounted
Output Current, Heavy-Duty Use (IHD) 45 A
Output Current, Normal Use (In) 59 A
Output Power, Heavy-Duty Use (PHD) 22 kW
Output Power, Normal Use (Pn) 30 kW
Efficiency Level IE2

ABB Complete Drive Module Efficiency (61800-9-2)

Operating Point Absolute Loss Relative Loss Efficiency
0 / 25 % 294 W 0.7 % 88.0 %
0 / 50 % 404 W 1.0 % 91.2 %
0 / 100 % 741 W 1.8 % 91.8 %
50 / 25 % 325 W 0.8 % 93.3 %
50 / 50 % 466 W 1.1 % 94.9 %
50 / 100 % 879 W 2.2 % 95.2 %
90 / 50 % 523 W 1.3 % 96.8 %
90 / 100 % 1051 W 2.6 % 96.7 %

ABB Classifications

UNSPSC 39122001
WEEE Category 4. Large Equipment (Any External Dimension More Than 50 cm)
