FBI10E Foxboro Fieldbus Isolator Invensys

In stock
Manufacturer:
Foxboro
Product No.:
FBI10E
Condition:
In Stock
Product Type:
Fieldbus Isolator
Product Origin:
USA
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

🔌 Network Activity Indicators

  • CP60 to FBI10E: Active: Amber, Inactive: Off
  • FBI10E to CP60: Active: Amber, Inactive: Off
  • FBI10E to FBMs (FBM01, FBM02, etc.): Active: Amber, Inactive: Off
  • FBMs (FBM01, FBM02, etc.) to FBI10E: Active: Amber, Inactive: Off

⏰ Internal Clock Indicators

  • Active: Green
  • Inactive: Red

⚡ Electrical Specifications

Parameter Details
🔋 Input Power Voltage
  • Normal Operating Range: 26 V DC to 42 V DC
  • Operating Current at 26 V DC: Maximum 350 mA
  • Power Dissipation at 42 V DC: Maximum 7.5 W
🔋 Battery Backup Power
  • Typical: 18 V DC
  • Minimum: 15 V DC
  • Maximum under Battery Operation: 21 V DC

🌡 Environmental Specifications

Parameter Details
🌡 Operating Temperature
  • Range: 0 to 60°C (32 to 140°F)
  • Relative Humidity: 5 to 95% (non-condensing)
  • Altitude: -300 to +3,000 m (-1,000 to +10,000 ft)
📦 Storage Conditions
  • Temperature: -40 to +85°C (-40 to +192°F)
  • Relative Humidity: 5 to 95% (non-condensing)
  • Altitude: -300 to +12,000 m (-1,000 to +40,000 ft)

🔧 Contamination Level

  • Class G3: Harsh, as defined in ISA Standard S71.04

🔉 Mechanical Vibration

  • 0.5 g: at 5 to 500 Hz

📜 Regulatory Compliance

  • Compliance: European EMC Directive 89/336/EEC

🔩 Mounting Options

  • With Y-Adapter: Installable in Industrial Enclosures 16 and 32, IEMFA/IEMFR, FEM 8, and Field Enclosure 8
  • Without Y-Adapter: Installable only in a 1x8, 1x8 FBM, or 1x12 FBM mounting structure

📏 Physical Specifications

  • Mass: 0.3 kg (0.7 lb)
  • Dimensions:
    • Height: 2.63 in (69 mm)
    • Width: 1.4 in (36 mm)
    • Depth: 17.9 in (413 mm)
