Enhanced Communication Module | MVI69E-MBTCP ProSoft
Manufacturer:
ProSoft
Product No.:
MVI69E-MBTCP
Condition:
In Stock
Product Type:
Enhanced Communication Module
Product Origin:
USA
Weight:
270g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
📝 Product Details
| Part Number/Catalog No.: | MVI69E-MBTCP |
| Manufacturer: | ProSoft Technology |
| Brand: | Allen-Bradley |
| Product Type: | Modbus TCP/IP Enhanced Communication Module |
| Rockwell Compatible Series: | CompactLogix |
🔧 Specifications
| Module Width: | Single slot |
| Compatible Rack: | 1769 CompactLogix |
| Communication Port: | One (1) RJ45 interface |
| Data Rate: | 10 / 100 Mbps |
| Data Size: | 10,000 words |
| Power Supply Distance Rating: | 4 |
| I/O Size: | 60/120/240 - 16 bit integers |
🌡️ Environmental Conditions
| Operating Temperature: | 32° F to 140° F (0° C to 60° C) |
| Storage Temperature: | -40° F to 185° F (-40° C to 85° C) |
| Operating Shock: | 30 g |
| Relative Humidity: | 5% to 95% (without condensation) |
🔌 Power and Connections
| Backplane Current Load: | 500 mA @ 5.1 VDC |
| Current Load: | 500 mA @ 5 VDC |
| Commands per Client Connection: | 16 max. |
| Modbus Client Connections: | 20 |
| Floating Point Data: | Supported |
| Configuration Software: | ProSoft Configuration Builder |
🔹 Additional Features
| LED Indicators: | Configuration Status, Application Status, Backplane Connectivity Status, Module Status |
| EMC Standards: | Conforms to EN 61326-1 |
| Module Isolation: | 1500 Vrms |
| Module MTBF: | 130,000 hours |
| Protocol Support: | Modbus TCP/IP |
