DS200TCPAG1AJD GE Turbine Control Processor Board

Technical Specifications:

• Part Number: DS200TCPAG1AJD
• Power Supply: 24 VDC nominal (typically 18-30 VDC range)
• Operating Temperature Range: -40°C to +85°C
• Processor: High-speed 32-bit processor for fast control calculations
• Memory: 4 MB SRAM, 8 MB Flash Memory
• Communication Ports:
  • Ethernet (TCP/IP)
  • RS-232/RS-485 serial communication
  • Proprietary GE communication protocols
• Digital I/O:
  • 16 digital inputs (24 VDC)
  • 16 digital outputs (24 VDC)
• Analog I/O:
  • 4 analog inputs (0-10 VDC, 4-20 mA)
  • 2 analog outputs (0-10 VDC, 4-20 mA)
• Status Indicators: LED status indicators for power, communication, and fault monitoring
• Fault Detection: Real-time fault detection and self-diagnostic capabilities
• Mounting: DIN rail or panel mount options
• Size: 6.5" x 6.5" (165 mm x 165 mm)
