Compact IO To DSI Communication module | AB 1769-SM2
Manufacturer:
Allen-Bradley
Product No.:
1769-SM2
Condition:
In Stock
Product Type:
Compact IO To DSI Communication module
Product Origin:
USA
Weight:
900g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Allen-Bradley 1769-SM2 Module Specifications
| Attribute | Value |
|---|---|
| Brand | Allen-Bradley |
| Part Number/Catalog No. | 1769-SM2 |
| Manufacturer | Rockwell Automation |
| Product Description | Compact I/O DSI / MODBUS communication module |
| Module Width | Single Slot |
| Compatible Controllers | CompactLogix, MicroLogix 1500 |
| Compatible PowerFlex Drives | PowerFlex 4 and PowerFlex 7 class drives |
| Supported Protocols | Drive Serial Interface (DSI), MODBUS RTU |
| DSI Data Transfer Speed | 19200 bps |
| MODBUS Transfer Speed | 300 to 38400 bps |
| Current Draw | 350 mA @ 5Vdc, 0 mA @ 24Vdc |
| Mounting | DIN Rail, Panel Mounting |
| Operating Temperature | -10…50 °C (14…122 °F) |
| Storage Temperature | -40…85 °C (-40…185 °F) |
| Vibration | 5g, 10 to 500 Hz |
| Operating Shock | 30g, 11 ms |
| Power Supply Distance Rating | 8 Modules |
| Series | A and B |
| Shipping Weight | 0.9 kg (2 lbs) |
| Shipping Dimensions | 20.3 x 20.3 x 12.7 cm (8 x 8 x 5 in) |
| Humidity | 5% to 95% non-condensing |
| Enclosure Type Rating | IP20 (Open Style) |
| Certifications | UL, CE, C-Tick, ATEX |
| Weight | 0.36 kg (0.79 lbs) |
