CC-PAOH51 Honeywell HART Analog Output Module In Stock
Manufacturer:
Honeywell
Product No.:
CC-PAOH51
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
USA
Weight:
350g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
CC-PAOH51 Honeywell 51410070-275 Specification:
- Output Channels: 16
- Output Signals: 4-20mA, 0-20mA, 0-10V
- HART Support: Yes
-
Isolation:
- Channel-to-channel: 500V
- Channel-to-system: 1500V
- Accuracy: ±0.1% of full scale
- Resolution: 16-bit
- Response Time: <20ms
- Power Supply: 24VDC (18-30VDC)
- Power Consumption: 4W max
- Output Ripple: < 100 mV peak-to-peak at power line frequency, across 250 Ω load
- Output Temperature Drift: 0.005% of Full Scale/°C
- Output Readback Accuracy: ±4% of Full Scale
- Output Current Linearity: ±0.05% of Full Scale nominal
- Calibrated Accuracy: ±0.35% of Full Scale (25°C) including linearity
- Directly Settable Output Current Range: 0 mA, 2.9 mA to 21.1 mA
- Maximum Resistive Load (24 V supply = 22 VDC through 28 VDC): 800 ohms
- Weight: 0.35 kg
