Bently Nevada 990-04-70-02-CN Vibration Transmitter
Manufacturer:
Bently Nevada
Product No.:
990-04-70-02-CN
Condition:
In Stock
Product Type:
990 Vibration Transmitter
Product Origin:
USA
Weight:
820g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🛠 Technical Specifications
Model Information
| Parameter | Specification |
|---|---|
| 🔧 Model | 990-04-70-02-CN |
| 🏢 Manufacturer | Bently Nevada |
| ⚙️ Series | 990 Vibration Transmitter |
| 📏 System Length | 7.0 meters (23.0 feet) |
| 🔄 Full-Scale Option | 0-4 mils pp (0-100 µm pp) |
| 🛠 Probe Tip Material | Polyphenylene sulfide (PPS) |
| 🛠 Probe Case Material | AISI 303 or 304 stainless steel (SST) |
| 🔌 Probe Cable | 75 Ω coaxial, FEP insulated |
| 💪 Tensile Strength | 222 N (50 lbf) |
| ⚖️ Weight | 0.82 Kg (1.81 lbs) |
| 🌡️ Operating Temperature Range | -35°C to +85°C (-31°F to +185°F) |
| 🌡️ Storage Temperature Range | -52°C to +100°C (-62°F to +212°F) |
| 🔩 Mounting Option | Bulkhead screws (02) |
| ✅ Agency Approvals | Country-specific (CN) |
Measurement and Performance
| Parameter | Specification |
|---|---|
| 📏 Vibration Measurement Range | 0-4 mils pp (0-100 µm pp) |
| 🔌 Transmitter Output | Standard 4-20 mA DC |
| 🔋 Power Supply | 24V DC (Nominal) |
| 🎯 Accuracy | ±1% of full scale |
| 🌍 Environmental Protection | IP65 rated |
| ✅ Compliance Standards | CE, UL, and other relevant certifications |
| 🎶 Frequency Response | 10 Hz to 10 kHz |
| 🔌 Input Impedance | ≥ 100 kΩ |
| 🔌 Output Impedance | 250 Ω (current output) |
| ⏱️ Response Time | ≤ 500 ms for 90% step change |
| 💥 Shock Resistance | 50 g for 11 ms duration |
| 🔊 Vibration Resistance | Up to 10 g RMS (20-2000 Hz) |
| 🔌 Connection | DIN or equivalent connectors |
